This isn't a direct answer, but should give you some pointers.
Historically the guest's expiry time was recorded in the associated device's Endpoint repository (MAC-Auth Expiry attribute - I believe Ben Van Zeggelaar came up with this solution back in 2013), along with the Username and Guest Role ID attributes, at registration time. A limitation of this approach is that subsequent changes in the guest's expiry time are not reflected in the Endpoint.
To address this I have taken a different approach. I still record the Username and Guest Role ID in the Endpoint but directly reference the guest's expiry time. To achieve this I've created a new [Guest User Repository] Attribute filter. The key thing is the SQL that extracts the guest's expiry time based on the Connection:Client-Mac-Address-NoDelim value - this is "normalized" to the correct format for the PostgreSQL database (I realise this should be Username but I can't guarantee this will be in the correct format):
SELECT CASE WHEN expire_time>now() THEN CAST(EXTRACT(epoch FROM (expire_time-NOW())) AS INTEGER)
ELSE 0
END AS remaining_expiration, expire_time::timestamp,
attributes->>'Role ID' AS role_id
FROM tips_guest_users
WHERE ((guest_type='USER') AND (user_id='%{Connection:Client-Mac-Address-NoDelim}') AND (app_name!='Onboard'))
The returned attributes are exposed in ClearPass in the following manner:
|
SQL Value
|
ClearPass attribute name
|
Data Type
|
|
remaining_expiration
|
MAC_ExpiresIn
|
Integer64
|
|
expire_time
|
MAC_ExpireTime
|
DateTime
|
|
role_id
|
MAC_RoleID
|
Integer
|
Within the Guest MAC-Auth service I can then add the [Guest User Repostory] as an Authorization Source (this should already be there). Within the RoleMapping I can build a condition that verifies whether this device's associated guest has expired:
(Endpoint:Guest Role ID EQUALS 251) AND (Authorization:[Time Source]:Now LESS_THAN %{Authorization:[Guest User Repository]:MAC_ExpireTime})
------------------------------
Derin Mellor
------------------------------
