Comware

In Procurve (ArubeOS) it is so easy to "correct"

https://community.arubanetworks.com/community-home/digestviewer/viewthread?MID=25863

In Comware

ssl version ssl3.0 disable
ssl version tls1.0 disable
ssl version tls1.1 disable

and

ssl server-policy my-server-policy
ciphersuite DHE_RSA_AES_128_CBC_SHA DHE_RSA_AES_128_CBC_SHA256 DHE_RSA_AES_256_CBC_SHA DHE_RSA_AES_256_CBC_SHA256 ECDHE_RSA_AES_128_CBC_SHA256 ECDHE_RSA_AES_128_GCM_SHA256 ECDHE_RSA_AES_256_CBC_SHA384 ECDHE_RSA_AES_256_GCM_SHA384 RSA_AES_128_CBC_SHA RSA_AES_128_CBC_SHA256 RSA_AES_256_CBC_SHA RSA_AES_256_CBC_SHA256

"Ofcourse" in Comware SSL needs to be restarted with

#undo ip https ena

#ip https ena

 After that it is all correct:

PORT    STATE SERVICE443/tcp open  https| ssl-cert: Subject: commonName=HPE5900-SR1..*****.local/countryName=GB| Issuer: commonName=****-EntCA| Public Key type: rsa| Public Key bits: 2048| Signature Algorithm: sha256WithRSAEncryption| Not valid before: 2019-07-10T12:32:11| Not valid after:  2021-07-09T12:32:11| MD5:   3bb8 a0fd 2480 89c2 122f fc9c 87b6 26d5|_SHA-1: 9132 310c 4a00 40ee 6bd6 e41e 6a8f 4e3a 230f a09c| ssl-enum-ciphers:|   TLSv1.2:|     ciphers:|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A|     compressors:|       NULL|     cipher preference: client|     warnings:|       Key exchange (dh 1024) of lower strength than certificate key|_  least strength: A

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (<= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (>= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (<= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (> 64-bit and < 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

And what is your certificate? Is it ECDHE ?

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

And what is your certificate? Is it ECDHE ?

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

I also tried, cause why not, switching out the policies to match that which is displayed when no ssl server policy is applied.  IE

[code]
[HP-BuildRoom-24]display ssl server-policy
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         RSA_AES_128_CBC_SHA
         RSA_AES_256_CBC_SHA
         DHE_RSA_AES_128_CBC_SHA
         DHE_RSA_AES_256_CBC_SHA
         RSA_AES_128_CBC_SHA256
         RSA_AES_256_CBC_SHA256
         DHE_RSA_AES_128_CBC_SHA256
         DHE_RSA_AES_256_CBC_SHA256
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]

However, Nmap still shows the same thing after, no ciphers being displayed at all

And what is your certificate? Is it ECDHE ?

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

I get this:

<HPE5900-SR1>display ssl server-policyTotal number of SSL server policies: 1 SSL server policy: domain-ssl     PKI domain: domain     Ciphersuites:         RSA_AES_128_CBC_SHA         RSA_AES_256_CBC_SHA         DHE_RSA_AES_128_CBC_SHA         DHE_RSA_AES_256_CBC_SHA         RSA_AES_128_CBC_SHA256         RSA_AES_256_CBC_SHA256         DHE_RSA_AES_128_CBC_SHA256         DHE_RSA_AES_256_CBC_SHA256         ECDHE_RSA_AES_128_CBC_SHA256         ECDHE_RSA_AES_256_CBC_SHA384         ECDHE_RSA_AES_128_GCM_SHA256         ECDHE_RSA_AES_256_GCM_SHA384     Session cache size: 500     Client-verify: disabled

I also tried, cause why not, switching out the policies to match that which is displayed when no ssl server policy is applied.  IE

[code]
[HP-BuildRoom-24]display ssl server-policy
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         RSA_AES_128_CBC_SHA
         RSA_AES_256_CBC_SHA
         DHE_RSA_AES_128_CBC_SHA
         DHE_RSA_AES_256_CBC_SHA
         RSA_AES_128_CBC_SHA256
         RSA_AES_256_CBC_SHA256
         DHE_RSA_AES_128_CBC_SHA256
         DHE_RSA_AES_256_CBC_SHA256
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]

However, Nmap still shows the same thing after, no ciphers being displayed at all

And what is your certificate? Is it ECDHE ?

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

self-signed cert?

I get this:

<HPE5900-SR1>display ssl server-policyTotal number of SSL server policies: 1 SSL server policy: domain-ssl     PKI domain: domain     Ciphersuites:         RSA_AES_128_CBC_SHA         RSA_AES_256_CBC_SHA         DHE_RSA_AES_128_CBC_SHA         DHE_RSA_AES_256_CBC_SHA         RSA_AES_128_CBC_SHA256         RSA_AES_256_CBC_SHA256         DHE_RSA_AES_128_CBC_SHA256         DHE_RSA_AES_256_CBC_SHA256         ECDHE_RSA_AES_128_CBC_SHA256         ECDHE_RSA_AES_256_CBC_SHA384         ECDHE_RSA_AES_128_GCM_SHA256         ECDHE_RSA_AES_256_GCM_SHA384     Session cache size: 500     Client-verify: disabled

I also tried, cause why not, switching out the policies to match that which is displayed when no ssl server policy is applied.  IE

[code]
[HP-BuildRoom-24]display ssl server-policy
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         RSA_AES_128_CBC_SHA
         RSA_AES_256_CBC_SHA
         DHE_RSA_AES_128_CBC_SHA
         DHE_RSA_AES_256_CBC_SHA
         RSA_AES_128_CBC_SHA256
         RSA_AES_256_CBC_SHA256
         DHE_RSA_AES_128_CBC_SHA256
         DHE_RSA_AES_256_CBC_SHA256
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]

However, Nmap still shows the same thing after, no ciphers being displayed at all

And what is your certificate? Is it ECDHE ?

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities

No, local MS AD CA issued certificate

self-signed cert?

I get this:

<HPE5900-SR1>display ssl server-policyTotal number of SSL server policies: 1 SSL server policy: domain-ssl     PKI domain: domain     Ciphersuites:         RSA_AES_128_CBC_SHA         RSA_AES_256_CBC_SHA         DHE_RSA_AES_128_CBC_SHA         DHE_RSA_AES_256_CBC_SHA         RSA_AES_128_CBC_SHA256         RSA_AES_256_CBC_SHA256         DHE_RSA_AES_128_CBC_SHA256         DHE_RSA_AES_256_CBC_SHA256         ECDHE_RSA_AES_128_CBC_SHA256         ECDHE_RSA_AES_256_CBC_SHA384         ECDHE_RSA_AES_128_GCM_SHA256         ECDHE_RSA_AES_256_GCM_SHA384     Session cache size: 500     Client-verify: disabled

I also tried, cause why not, switching out the policies to match that which is displayed when no ssl server policy is applied.  IE

[code]
[HP-BuildRoom-24]display ssl server-policy
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         RSA_AES_128_CBC_SHA
         RSA_AES_256_CBC_SHA
         DHE_RSA_AES_128_CBC_SHA
         DHE_RSA_AES_256_CBC_SHA
         RSA_AES_128_CBC_SHA256
         RSA_AES_256_CBC_SHA256
         DHE_RSA_AES_128_CBC_SHA256
         DHE_RSA_AES_256_CBC_SHA256
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]

However, Nmap still shows the same thing after, no ciphers being displayed at all

And what is your certificate? Is it ECDHE ?

With no policy applied I get this
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
| ssl-enum-ciphers:
|   TLSv1.2:
|     ciphers:
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_128_CBC_SHA256 (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA (dh 1024) - A
|       TLS_DHE_RSA_WITH_AES_256_CBC_SHA256 (dh 1024) - A
|       TLS_ECDHE_RSA_WITH_AES_128_CBC_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_CBC_SHA384 (secp256r1) - A
|       TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384 (secp256r1) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_128_CBC_SHA256 (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA (rsa 2048) - A
|       TLS_RSA_WITH_AES_256_CBC_SHA256 (rsa 2048) - A
|     compressors:
|       NULL
|     cipher preference: client
|     warnings:
|       Key exchange (dh 1024) of lower strength than certificate key
|_  least strength: A
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 7.76 seconds
[/code]

Then I apply the following server policy
[code]
Total number of SSL server policies: 1
 SSL server policy: examplepolicyfromhp
     PKI domain:
     Ciphersuites:
         ECDHE_RSA_AES_128_CBC_SHA256
         ECDHE_RSA_AES_256_CBC_SHA384
         ECDHE_RSA_AES_128_GCM_SHA256
         ECDHE_RSA_AES_256_GCM_SHA384
     Session cache size: 500
     Caching timeout: 3600 seconds
     Client-verify: Disabled
     Certificate chain sending: Disabled
[/code]
After applying the ssl server policy and running the nmap
[code]

Host is up (0.0010s latency).

PORT    STATE SERVICE
443/tcp open  https
MAC Address: 4C:AE:A3:C3:90:94 (Hewlett Packard Enterprise)

Nmap done: 1 IP address (1 host up) scanned in 3.52 seconds
[/code]
SSL3.0, TLS1.0, and TLS1.1 are all disabled as well but enabling them doesn't seem to resolve anything.  There is no rhyme or reason to that specific cipher set.  Just happened to be the last set of ciphers that I tried.
Thanks for the response!

What what does nmap show?

nmap --script ssl-enum-ciphers -p 443 host_IP_or_DNS

@jmpk I've followed what you've listed above, however, no matter what ciphersuites I select, once I apply the server policy to HTTPS, I get a "This site can't provide a secure connection <IP> uses an unsupported protocol.
ERR_SSL_VERSION_OR_CIPHER_MISMATCH
Unsupported protocol
The client and server don't support a common SSL protocol version or cipher suite." error.  I've tried multiple permutations but every one ends the same, I can't get into the web config with the SSL server-policy enabled.  Suggestions?

Original Message:
Sent: Mar 31, 2021 03:08 AM
From: jmpk
Subject: HPE Switch - SSL Vulnerabilities.

Users may see following Plugin name or Vulnerabilities on their security assessment report . Below is example one, but the plugin name will be same for all customer

Plugin Name

SSL RC4 Cipher Suites Supported (Bar Mitzvah)

Plugin Output:  List of RC4 cipher suites supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export         High Strength Ciphers (&gt;= 112-bit key)      RC4-MD5                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=MD5         RC4-SHA                      Kx=RSA         Au=RSA      Enc=RC4(128)             Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Weak Cipher Suites Supported

Plugin Output:  Here is the list of weak SSL ciphers supported by the remote server :    Low Strength Ciphers (&lt;= 64-bit key)      EXP-DES-CBC-SHA              Kx=RSA(512)    Au=RSA      Enc=DES-CBC(40)          Mac=SHA1   export          EXP-RC2-CBC-MD5              Kx=RSA(512)    Au=RSA      Enc=RC2-CBC(40)          Mac=MD5    export          EXP-RC4-MD5                  Kx=RSA(512)    Au=RSA      Enc=RC4(40)              Mac=MD5    export          DES-CBC-SHA                  Kx=RSA         Au=RSA      Enc=DES-CBC(56)          Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

SSL Medium Strength Cipher Suites Supported (SWEET32)

Plugin Output:    Medium Strength Ciphers (&gt; 64-bit and &lt; 112-bit key  or 3DES)      DES-CBC3-SHA                 Kx=RSA         Au=RSA      Enc=3DES-CBC(168)        Mac=SHA1     The fields above are :    {OpenSSL ciphername}   Kx={key exchange}   Au={authentication}   Enc={symmetric encryption method}   Mac={message authentication code}   {export flag}

Users needs to create an SSL server-policy and choose the secured cipher suit. Then link this newly created SSL server-policy to the ip https service.

However from my point of view, customer don't need the http and https service as to configure and manage the switch as we use SSH.

Users can just disable the ip http and https service to mitigate this vulnerability.

Config Example for SSL:

==

ssl version ssl3.0 disable

ssl version tls1.0 disable

ssl server-policy myserverpolicy ciphersuite  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

ssl client-policy myclientpolicy prefer-cipher  dhe_rsa_aes_128_cbc_sha  dhe_rsa_aes_256_cbc_sha  exp_rsa_des_cbc_sha  rsa_3des_ede_cbc_sha  rsa_aes_128_cbc_sha  rsa_aes_256_cbc_sha  rsa_des_cbc_sha

==

[5940-133-32-ssl-server-policy- myserverpolicy]ciphersuite ?

  dhe_rsa_aes_128_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_128_CBC_SHA

  dhe_rsa_aes_128_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_128_CBC_SHA256

  dhe_rsa_aes_256_cbc_sha         Use the ciphersuit

                                  SSL_DHE_RSA_with_AES_256_CBC_SHA

  dhe_rsa_aes_256_cbc_sha256      Use the ciphersuit

                                  TLS_DHE_RSA_with_AES_256_CBC_SHA256

  ecdhe_ecdsa_aes_128_cbc_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_CBC_SHA256

  ecdhe_ecdsa_aes_128_gcm_sha256  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_128_GCM_SHA256

  ecdhe_ecdsa_aes_256_cbc_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_CBC_SHA384

  ecdhe_ecdsa_aes_256_gcm_sha384  Use the ciphersuit

                                  TLS_ECDHE_ECDSA_with_AES_256_GCM_SHA384

  ecdhe_rsa_aes_128_cbc_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_CBC_SHA256

  ecdhe_rsa_aes_128_gcm_sha256    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_128_GCM_SHA256

  ecdhe_rsa_aes_256_cbc_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_CBC_SHA384

  ecdhe_rsa_aes_256_gcm_sha384    Use the ciphersuit

                                  TLS_ECDHE_RSA_with_AES_256_GCM_SHA384

  exp_rsa_des_cbc_sha             Use the ciphersuit

                                  SSL_RSA_export_with_DES_CBC_SHA

  exp_rsa_rc2_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC2_CBC_40_MD5

  exp_rsa_rc4_md5                 Use the ciphersuit

                                  SSL_RSA_export_with_RC4_40_MD5

  rsa_3des_ede_cbc_sha            Use the ciphersuit

                                  SSL_RSA_with_3DES_EDE_CBC_SHA

  rsa_aes_128_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_128_CBC_SHA

  rsa_aes_128_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_128_CBC_SHA256

  rsa_aes_256_cbc_sha             Use the ciphersuit

                                  SSL_RSA_with_AES_256_CBC_SHA

  rsa_aes_256_cbc_sha256          Use the ciphersuit

                                  TLS_RSA_with_AES_256_CBC_SHA256

  rsa_des_cbc_sha                 Use the ciphersuit SSL_RSA_with_DES_CBC_SHA

  rsa_rc4_128_md5                 Use the ciphersuit SSL_RSA_with_RC4_128_MD5

  rsa_rc4_128_sha                 Use the ciphersuit SSL_RSA_with_RC4_128_SHA

#SSLWeakCipherSuites
#SSLRC4CipherSuites
#SSLVulnerabilities
